1.9m Tall Enclosed Passenger Trike (6-Seater) | Factory FCL – ORVIK

Wholesale enclosed electric passenger trike (6-seater) with a narrow 1m profile & 1.9m tall cabin. Built-in heater & Arctic-ready. Get factory FCL quotes.

Get Factory Quote Now
Categories: , Tags: , , , , ,

Description

The ORVIK DDC IV offers a unique geometric advantage for off-road resort and industrial transit: a highly maneuverable narrow profile (1010mm width) combined with an exceptionally tall cabin (1900mm height). This specific design allows the vehicle to easily navigate tight campus pathways or narrow factory aisles, while still comfortably transporting 5 to 6 passengers with superior, VIP-level headroom. The fully enclosed, weather-sealed cabin features an integrated heater, providing absolute protection against freezing environments or dusty mining sites.

Built upon a robust framework with rear leaf spring suspension and a three-wheel disc braking system, this shuttle ensures a stable and safe ride even on uneven terrain. By adopting an electric powertrain, you eliminate internal combustion engine maintenance and noise, drastically lowering your Total Cost of Ownership (TCO). To meet diverse global climates, the battery system is fully customizable (Lead-acid or extreme-temperature LiFePO4). While equipped with a 1000W standard motor, we highly recommend customizing the power output for steep inclines, or adding optional hybrid range extenders and solar panels for off-grid endurance. Built for tight spaces. Built direct. Designed to make your work flow.

Parameter Category Specification Details
Overall Dimensions (L*W*H) 2850 1010 1900 mm
Passenger Capacity 5 – 6 Persons (Including Driver)
Voltage 60-72V Universal
Motor Power 1000W Standard (Custom Power Upgrades Highly Recommended for 6-pax load)
Controller Dual 18-tube Controller
Battery Type Customizable (Lead-acid / LiFePO4)
Suspension Front Hydraulic / Rear Leaf Spring Steel Plate
Braking System Three-Wheel Disc Brakes
Tire Size Front: 3.75-12 / Rear: 4.00-12
Main Configurations Integrated LCD Dashboard, Rearview Camera, Cabin Heater, Radio
Optional Upgrades Hybrid Range Extender, Solar Power Generation Roof
Max Speed Strictly Limited (Off-road / Private Property Use Only)
Loading Qty (40HQ) Approx. 20-25 Units (SKD – Contact for precise container layout due to 1.9m extreme height)

Additional information

Overall Dimensions (L*W*H)

2850 * 1010 * 1900 mm
Passenger Capacity

5 – 6 Persons (Including Driver)
Voltage

60-72V Universal
Motor Power

1000W Standard (Custom Power Upgrades Highly Recommended for 6-pax load)
Controller

Dual 18-tube Controller
Battery Type

Customizable (Lead-acid / LiFePO4)
Suspension

Front Hydraulic / Rear Leaf Spring Steel Plate
Braking System

Three-Wheel Disc Brakes
Tire Size

Front: 3.75-12 / Rear: 4.00-12
Main Configurations

Integrated LCD Dashboard, Rearview Camera, Cabin Heater, Radio
Optional Upgrades

Hybrid Range Extender, Solar Power Generation Roof
Max Speed

Strictly Limited (Off-road / Private Property Use Only)
Loading Qty (40HQ)

Approx. 20-25 Units (SKD – Contact for precise container layout due to 1.9m extreme height)

B2B Buying Guide & FAQ

What is the Minimum Order Quantity (MOQ)? Can I buy a sample?、

Our supply chain is optimized for FCL (Full Container Load) efficiency.

  • Bulk Orders: Standard MOQ is 1 Container (20GP or 40HQ).
  • Sample Policy: Yes, we support validation. Sample units are available at a “Partner Qualification Rate” (approx. 90% of the standard price) to help you test the market with lower risk

Are these vehicles legal for public road use?

Standard ORVIK models are engineered for Off-Road and Private Property Use (e.g., Resorts, Mines, Farms).

  • Customization: However, Street-Legal Compliance Customization is available for specific models (e.g., meeting L7e standards).
  • Action: Please contact our sales engineers to discuss your local registration requirements and feasibility

Can I customize the specifications for my market?

Yes. As a factory-direct source, we offer deep technical customization.

  • Climate Packages: “High-Temp Ready” (Middle East) or “Arctic Ready” (Russia/CIS)
  • Technical Specs: Customization includes Battery (Lead-acid/LiFePO4), Motor Power, and Chassis reinforcement

How do you handle spare parts and warranty?

  • Warranty: 1 Year for Vehicle Core, 5 Years for LiFePO4 Batteries.
  • Spare Parts: We recommend purchasing a “Suggested Spare Parts Kit” with your container order to ensure immediate local service and minimize downtime

What is the lead time for production?

Our standard production cycle is rapid—typically 8-10 days (Ex-Works) after deposit. This allows you to maintain a lean inventory while responding quickly to market demand
