1000W Electric Cargo Trike for Farm & Mining | Factory FCL – ORVIK

Wholesale 1000W electric cargo trike featuring an extended 1.5m bed and 12-inch tires for bulky loads. Arctic/High-temp ready. Get your factory FCL quote today.

Get Factory Quote Now
Categories: , Tags: , , , , ,

Description

The ORVIK SK1.5 steps up your hauling capability with an extended 1.5m cargo bed and larger 12-inch tires, engineered strictly for off-road and industrial property use. Built upon a reinforced framework and heavy-duty rear leaf spring suspension, this workhorse is designed to transport up to 500kg of bulky materials—such as agricultural harvest or construction debris—across uneven, challenging terrains without bottoming out. The larger wheel diameter translates directly to higher ground clearance, giving your operators the confidence to navigate muddy farm trails or gravel mining sites.

By utilizing a direct rear-axle differential drive, the SK1.5 eliminates high-maintenance transmission components, drastically reducing your fleet’s total cost of ownership (TCO) and operational downtime. To accommodate varying global climates, the battery system is fully customizable; choose cost-effective Lead-acid for standard use, or high-density LiFePO4 for extreme temperature environments. When your operational demands scale up, so do we: while the standard 1000W motor delivers robust torque, the power system is customizable with options to upgrade to 1200W/1500W motors or install a range extender for uninterrupted heavy-duty cycles. Built for the grind. Designed to make your work flow.

Parameter Category Specification Details
Cargo Bed Dimensions (L*W*H) 1500 * 1000 mm
Body Structure Reinforced Framework Structure
Voltage 48-60V Universal
Motor Power 1000W Standard (Customizable up to 1200W/1500W)
Battery Type Customizable (Lead-acid / LiFePO4)
Drive System Rear axle integrated differential
Suspension Front Hydraulic / Rear Leaf Spring Steel Plate
Braking System Front Hydraulic / Rear Dual Drum Brakes
Tire Size Front: 3.0-12 / Rear: 3.75-12
Max Speed 30-40 km/h (Off-road / Private Property Use Only)
Climbing Capacity 15 – 30 degrees
Rated Load Capacity 300 – 500 KG
Optional Devices Range Extender, Upgraded Motor
Loading Qty (40HQ) Approx. 45-55 Units (SKD – Contact for exact layout)

Additional information

Cargo Bed Dimensions (L*W*H)

1500 * 1000 mm
Body Structure

Reinforced Framework Structure
Motor Power

1000W Standard (Customizable up to 1200W/1500W)
Drive System

Rear axle integrated differential
Tire Size

Front: 3.0-12 / Rear: 3.75-12
Climbing Capacity

15 – 30 degrees
Rated Load Capacity

300 – 500 KG
Voltage

48-60V Universal
Battery Type

Customizable (Lead-acid / LiFePO4)
Suspension

Front Hydraulic / Rear Leaf Spring Steel Plate
Braking System

Front Hydraulic / Rear Dual Drum Brakes

B2B Buying Guide & FAQ

What is the Minimum Order Quantity (MOQ)? Can I buy a sample?、

Our supply chain is optimized for FCL (Full Container Load) efficiency.

  • Bulk Orders: Standard MOQ is 1 Container (20GP or 40HQ).
  • Sample Policy: Yes, we support validation. Sample units are available at a “Partner Qualification Rate” (approx. 90% of the standard price) to help you test the market with lower risk

Are these vehicles legal for public road use?

Standard ORVIK models are engineered for Off-Road and Private Property Use (e.g., Resorts, Mines, Farms).

  • Customization: However, Street-Legal Compliance Customization is available for specific models (e.g., meeting L7e standards).
  • Action: Please contact our sales engineers to discuss your local registration requirements and feasibility

Can I customize the specifications for my market?

Yes. As a factory-direct source, we offer deep technical customization.

  • Climate Packages: “High-Temp Ready” (Middle East) or “Arctic Ready” (Russia/CIS)
  • Technical Specs: Customization includes Battery (Lead-acid/LiFePO4), Motor Power, and Chassis reinforcement

How do you handle spare parts and warranty?

  • Warranty: 1 Year for Vehicle Core, 5 Years for LiFePO4 Batteries.
  • Spare Parts: We recommend purchasing a “Suggested Spare Parts Kit” with your container order to ensure immediate local service and minimize downtime

What is the lead time for production?

Our standard production cycle is rapid—typically 8-10 days (Ex-Works) after deposit. This allows you to maintain a lean inventory while responding quickly to market demand
